Fly Ash Brick Making Machine
A fly ash brick-making machine is a high-tech device to produce fly ash bricks of very high quality in an accurate and fast manner. This makes such machines crucial for sustainable construction since they will use fly ash, a combustion by-product from coal, in the manufacture of bricks that are environmentally friendly. The parts are a hydraulic press with good strength, a balanced mold system, and an automated controlling unit to consistently produce good quality bricks. The fly ash brick making machines are useful in manufacturing different sizes and shapes of bricks as required by different building activities. They are characterized by high production capacity, low labor, and minimal maintenance costs. The user-friendliness of the interface makes the machine easy to operate and control. Fly ash brick making machines are reliable and productive, hence helping attain the values of green buildings. Find the best quality fly ash brick-making machine available on Aajjo. For high-quality, reliable fly ash brick making machines combining functionality with precision, look up the top products on Aajjo.
Fully Automatic Fly Ash Brick Making Machine
₹
1,580,000.00
| General deatils: | |
| Model | Fully Automatic Fly Ash Brick Making Machine |
| Automation Grade | Automatic |
| Brick Type | Hollow |
| Capacity | 2000-2400 Bricks Per Hour |
| Brick Size | 230 X 110 X 75 mm |
| Tolerance | 0.5 mm |
| Others: | |
| Automation Grade - | Automatic |
| Brick Type - | Solid |
| Capacity - | 1500-2000 bricks per hour |
| Machine Weight - | 8000 Kg |
| Material - | Mild Steel |
| Method | Hydraulic - Pressure |
| Oil Tank Capacity - | 400 Liter |
| Place Of Origin | - India |
| System - | Hydraulic |
| Tolerance - | 0.5 mm |
| Warranty - | 1 Year |
| Usage/Application | Industrial |
| Land Require - | 0.75 Acer |
| Shed Area for Installation - | 3000 sq feet |
| Country of Origin - | Made in India |
| Rated Pressure - | 120 Ton |
| Vibration Frequency - | 5000 Hz |
| Molding Cycle - | Upto 7 strokes per Minute |
| Machine Dimension | - 50 X 6 X 12 feet |
| Motor Make - | Crompton Greaves |
| Motor Power - | 37 HP |
| Provide After Sales Service - | Yes |
High Pressure Fly Ash Brick Making Machine ensures a superior quality of output along with a noise free machine operation.
Fully Automatic Fly Ash Brick Making Machine
₹
1,500,000.00
| General deatils: | |
| Model | - ODBM 10FA |
| Automation Grade | Automatic |
| Brick Type | - Hollow |
| Capacity | - 2000-2400 Bricks Per Hour |
| Brick Size | - 230 X 110 X 75 mm |
| Tolerance | - 0.5 mm |
| Others: | |
| Brand - | Odisol |
| Usage/Application - | Industrial |
| Warranty - | 1 Year |
| Machine Weight - | 9000 kg |
| Maximum High Pressure | - 220 Bar |
| Oil Tank Capacity - | 400 Liter |
| Motor Power - | 37 HP |
| Motor Make - | Crompton Greaves |
| Machine Dimension - | 50 X 6 X 12 feet |
| Phase - | 3 Phase |
| Molding Cycle | - Upto 7 strokes per Minute |
| Rated Pressure - | 120 Ton |
| Vibration Frequency - | 5000 Hz |
| Pan Mixer Power - | Twin shaft or Rotary Pan Mixture |
| Provide After Sales Service - | Yes |
| Shed Area for Installation - | 3000 sq feet |
| Land Require - | 0.75 Acer |
| Country of Origin | - Made in India |
Solid Fully Automatic Fly Ash Brick Plant
₹
1,480,000.00
| General deatils: | |
| Method | Autoclave Aerated |
| Tolerance | 0.5 mm |
| Automation Grade | Automatic |
| Brick Type | Solid |
| Others: | |
| Capacity (Bricks Per Hour) | 1000 Bricks |
| Brick Raw Material | Concrete |
Features: Latest design & equipment. Highly efficient hydraulic & electrical design. Component with long service life. Heavy-duty jig welded main body design. Digitally aligned component during assembly. Even pressure distribution during pressing. Alloy steel is used for critical components. Built-in cooling system for efficient hydraulic circuit. Power saver arrangement, for power, saving up to 25%. Superior gearbox for longer service life. Hardened die for longer mold life. Easy to Install. Available Models and detials:ODBM 08M/ODBM 08A /ODBM 08AHS We have launched this improved design for the medium manufacturers. No of bricks in one stroke 8, maximum size 250x120x75. Cycle time of the machine – 15 seconds. System Pressure 100 Ton. Working Pressure - 200 Bar. Oil tank capacity - 400Liters of system 68 Hydraulic oil. Weight of the machine - 6800kg. Control- Siemens PLC. Model – Manual, Automatic, High speed. Production capacity - 15500 for the high-speed model. Power Requirement 35 HP. Model specification may vary depending upon the customer's requirement. Inbuilt oil cooling system. Power saver arrangement. Pallet & conveyor type.
